Einstein Crystal
One poster connects the Einstein crystal's fixed-site springs to quantum harmonic oscillators, heat capacity, Debye phonons, microstate counting, and solid free energies. A lattice sketch distinguishes springs to reference sites from interactions between atoms. Quantized levels and thermal populations explain the Einstein heat-capacity curve, its low-temperature freeze-out, and the classical Dulong–Petit limit. A comparison with the Debye spectrum shows why acoustic modes give a cubic low-temperature heat capacity. Six boxed explanations connect the variables to the physics, including restoring forces, equipartition, Debye's cutoff, and the mixing parameter used in free-energy calculations.
Six explicit allocations of two energy quanta among three modes illustrate entropy. The final panel introduces the classical Frenkel–Ladd method: a reversible path connects a solvable Einstein reference to an interacting solid. The thermodynamic-integration identity uses the same positional constraint at both endpoints; releasing that constraint requires the corresponding analytic free-energy correction. Einstein and Debye temperatures are set equal only to compare curve shapes, and the heat-capacity curves describe lattice vibrations rather than electronic or magnetic contributions.
Download
Code
einstein-crystal.typ (480 lines)
#import "@preview/cetz:0.5.2": canvas, draw
#import draw: circle, content, group, line, rect, set-origin
// N identical atoms give M = 3N independent scalar oscillators of frequency omega_E.
// Einstein and Debye curves use equal characteristic temperatures for shape comparison.
// Debye integration: composite Simpson quadrature; the exponentially small tail above
// x = 50 is omitted. All plotted values come from the helpers tested by Typst queries.
// The free-energy path is classical, at fixed temperature, volume, particle number,
// and positional constraint. Its endpoint free energies use that same constraint.
// https://www.physics.usyd.edu.au/~sflammia/Courses/StatMech2020/normal/3/n3.html
// https://doi.org/10.1002/andp.19123441404
// https://arxiv.org/abs/1210.3956
#set page(width: auto, height: auto, margin: 0pt, fill: none)
#set text(font: "Avenir Next", size: 18pt, fill: rgb("#19304E"))
#set par(leading: 0.48em)
#set math.equation(numbering: none)
#let ink = rgb("#19304E")
#let muted = rgb("#46566C")
#let blue = rgb("#2864BB")
#let teal = rgb("#06716E")
#let orange = rgb("#A84820")
#let purple = rgb("#7750A3")
#let guide = rgb("#8799AD")
#let blue_fill = rgb("#DDE6F0")
#let teal_fill = rgb("#D8E7E3")
#let orange_fill = rgb("#EDE1D5")
#let purple_fill = rgb("#E3DEEA")
// Heat capacity of one mode in units of k_B, x = hbar omega / (k_B T).
// sinh avoids cancellation at small x; the zero limit is analytic.
#let mode_cv(inverse_temperature) = {
assert(inverse_temperature >= 0)
if inverse_temperature == 0 { return 1 }
calc.pow(inverse_temperature / (2 * calc.sinh(inverse_temperature / 2)), 2)
}
#let einstein_cv(reduced_temperature) = {
assert(reduced_temperature >= 0)
if reduced_temperature == 0 { 0 } else { mode_cv(1 / reduced_temperature) }
}
#let debye_cv(reduced_temperature) = {
assert(reduced_temperature >= 0)
if reduced_temperature == 0 { return 0 }
let upper = calc.min(1 / reduced_temperature, 50)
let intervals = 400
let step = upper / intervals
let weighted_samples = range(intervals + 1).map(sample_idx => {
let position = step * sample_idx
let endpoint = sample_idx in (0, intervals)
let weight = if endpoint { 1 } else if calc.odd(sample_idx) { 4 } else { 2 }
weight * position * position * mode_cv(position)
})
let integral = weighted_samples.sum() * step / 3
3 * calc.pow(reduced_temperature, 3) * integral
}
#let level_probability(level, reduced_temperature) = {
assert(level >= 0 and reduced_temperature > 0)
(1 - calc.exp(-1 / reduced_temperature)) * calc.exp(-level / reduced_temperature)
}
#let allocations = {
let states = ()
for first in range(3) {
for second in range(3 - first) { states.push((first, second, 2 - first - second)) }
}
states
}
#let label(
left,
top,
width,
body,
size: 18pt,
color: muted,
weight: "regular",
centered: false,
) = content(
(left, top),
block(width: width * 1pt)[
#text(size: size, fill: color, weight: weight, if centered { align(center, body) } else {
body
})
],
anchor: "north-west",
padding: 0pt,
)
#let symbol(center_x, center_y, body, size: 18pt, color: ink) = content(
(center_x, center_y),
text(size: size, fill: color, body),
padding: 0pt,
)
#let equation = label.with(size: 24pt, color: ink, centered: true)
#let segment(start, end, color: guide, thickness: 1pt, dash: "solid") = line(
start,
end,
stroke: (paint: color, thickness: thickness, dash: dash),
)
#let arrow(start, end, color: ink, both: false) = line(start, end, stroke: 1.5pt + color, mark: (
start: if both { "stealth" } else { none },
end: "stealth",
scale: 0.65,
fill: color,
))
#let site(center_x, center_y, size: 5) = {
segment((center_x - size, center_y), (center_x + size, center_y), thickness: 1.3pt)
segment((center_x, center_y - size), (center_x, center_y + size), thickness: 1.3pt)
}
#let atom(center_x, center_y, radius: 8, color: blue) = circle(
(center_x, center_y),
radius: radius,
fill: color,
stroke: none,
)
// Zigzag with 5 full oscillations between straight end points.
#let spring(start, end, color: blue, amplitude: 2.4, thickness: 1.3pt) = {
let (delta_x, delta_y) = (end.at(0) - start.at(0), end.at(1) - start.at(1))
let distance = calc.sqrt(delta_x * delta_x + delta_y * delta_y)
assert(distance > 0)
let points = range(13).map(sample_idx => {
let wave = if sample_idx in (0, 12) { 0 } else if calc.odd(sample_idx) { amplitude } else {
-amplitude
}
(
start.at(0) + delta_x * sample_idx / 12 - delta_y * wave / distance,
start.at(1) + delta_y * sample_idx / 12 + delta_x * wave / distance,
)
})
line(..points, stroke: thickness + color)
}
// Panel background and numbered title; `body` is drawn relative to the panel's top-left corner.
#let panel(left, top, width, height, number, title, accent, fill, body) = group({
set-origin((left, top))
rect((0, 0), (width, height), radius: 12, fill: fill, stroke: none)
circle((30, 32), radius: 15, fill: accent, stroke: none)
symbol(30, 32, text(weight: "bold", fill: white, str(number)))
content(
(56, 34), // Optical centering against the badge.
block(width: (width - 78) * 1pt, text(size: 23pt, fill: ink, weight: "bold", title)),
anchor: "west",
padding: 0pt,
)
body
})
#let callout(left, top, width, accent, title, body) = content(
(left, top),
block(width: width * 1pt, inset: 12pt, radius: 7pt, fill: rgb("#F3F5F7"), stroke: (
left: 3pt + accent,
))[
#set par(leading: 0.35em)
#stack(
dir: ttb,
spacing: 7pt,
text(size: 18pt, fill: accent, weight: "bold", title),
text(size: 17pt, fill: muted, body),
)
],
anchor: "north-west",
padding: 0pt,
)
// Four fixed sites and their (displaced) atoms; coupling = λ blends springs into interactions.
#let reference_cell(center_x, center_y, coupling) = {
let positions = ((-24, -21), (24, -21), (-24, 21), (24, 21))
let offsets = ((10, -7), (-8, 8), (9, 6), (-9, -7))
let atoms = positions
.zip(offsets)
.map((((pos_x, pos_y), (off_x, off_y))) => (center_x + pos_x + off_x, center_y + pos_y + off_y))
if coupling > 0 {
for (first, second) in ((0, 1), (0, 2), (1, 3), (2, 3)) {
segment(
atoms.at(first),
atoms.at(second),
color: teal,
thickness: (0.8 + 1.2 * coupling) * 1pt,
)
}
}
for (idx, (pos_x, pos_y)) in positions.enumerate() {
let fixed = (center_x + pos_x, center_y + pos_y)
if coupling < 1 {
spring(fixed, atoms.at(idx), color: purple, thickness: (1.6 - coupling) * 1pt, amplitude: 2)
site(..fixed, size: 3.5)
}
atom(..atoms.at(idx), radius: 7, color: if coupling == 1 { teal } else { purple })
}
}
// Page coordinates: x increases rightward, y downward. Panel bodies are relative to their panel.
#canvas(length: 1pt, y: -1, {
rect((0, 0), (1180, 1952), fill: none, stroke: none)
label(28, 18, 1124, [Einstein crystal], size: 43pt, color: ink, weight: "bold")
label(
30,
78,
1110,
)[One solvable model connects atomic vibrations, quantum heat capacity, entropy, and solid free energies.]
// === Fixed-site model ===
panel(24, 123, 610, 518, 1, [Replace the crystal by local springs], blue, blue_fill, {
label(
21,
61,
567,
size: 19pt,
color: blue,
weight: "bold",
)[N atoms × 3 directions = M = 3N independent modes]
// displacement of each atom from its site on a 3×3 grid
let offsets = (
((20, -9), (-17, -10), (16, 13)),
((-15, 15), (24, -11), (-14, -15)),
((20, 7), (-16, 10), (16, -13)),
)
for (row, row_offsets) in offsets.enumerate() {
for (col, (offset_x, offset_y)) in row_offsets.enumerate() {
let (site_x, site_y) = (63 + col * 77, 117 + row * 56)
spring((site_x, site_y), (site_x + offset_x, site_y + offset_y))
site(site_x, site_y)
atom(site_x + offset_x, site_y + offset_y)
}
}
label(23, 251, 276, size: 16pt)[Cross: fixed site $bold(R)_i$\ Dot: atom at $bold(r)_i$]
let (axis_x, axis_y) = (453, 231)
label(axis_x - 114, axis_y - 131, 240, centered: true, size: 17pt)[One displacement coordinate]
arrow((axis_x - 112, axis_y), (axis_x + 127, axis_y), color: guide)
arrow((axis_x, axis_y), (axis_x, axis_y - 106), color: guide)
let parabola = range(101).map(sample_idx => {
let position = (sample_idx - 50) / 50
(axis_x + position * 96, axis_y - 8 - 87 * position * position)
})
line(..parabola, stroke: 2pt + blue)
site(axis_x, axis_y - 8)
circle((axis_x + 53, axis_y - 35), radius: 9, fill: blue, stroke: none, name: "displaced-atom")
arrow("displaced-atom.west", (rel: (-30, 0)), color: orange)
symbol(axis_x + 107, axis_y - 31, $F_u = -kappa u$, size: 17pt, color: orange)
symbol(axis_x + 127, axis_y + 18, $u$)
symbol(axis_x - 20, axis_y - 90, $V$)
label(340, 256, 244, size: 17pt, centered: true)[$bold(u)_i = bold(r)_i - bold(R)_i$]
equation(
19,
291,
571,
)[$V_"E" = kappa/2 sum_(i=1)^N |bold(u)_i|^2 quad omega_"E" = sqrt(kappa/m)$]
label(
19,
332,
566,
size: 15pt,
centered: true,
)[Same stiffness $kappa$ and mass $m$; springs attach to sites, not neighboring atoms.]
callout(20, 368, 570, blue, [Read the restoring force])[
$bold(u)_i$ is atom $i$’s displacement from its fixed site. The force points back toward the potential minimum: $F_u = -kappa u$. Doubling $|u|$ quadruples the spring energy. Stiffer springs or lighter atoms have a higher angular frequency $omega_"E"$. This harmonic approximation describes small vibrations about stable sites.
]
})
// === Quantized energy and populations ===
panel(652, 123, 504, 518, 2, [Heating fills a quantum ladder], orange, orange_fill, {
equation(22, 58, 458)[$E_n = (n + 1/2) ℏ omega_"E" quad n = 0,1,2,...$]
label(187, 103, 115, size: 16pt, color: blue, centered: true)[Cold\ $T = Theta_"E"/4$]
label(350, 103, 117, size: 16pt, color: orange, centered: true)[Warm\ $T = 2 Theta_"E"$]
let (ground_y, level_gap) = (274, 29)
for level in range(5) {
let level_y = ground_y - level * level_gap
symbol(53, level_y, $n = #level$, size: 16pt)
segment(
(89, level_y),
(161, level_y),
color: if level == 0 { orange } else { ink },
thickness: 1.7pt,
)
// bar length = probability of the level at the cold and warm temperatures
for (left, temperature, color) in ((192, 0.25, blue), (354, 2, orange)) {
let bar_right = left + 103 * level_probability(level, temperature)
rect((left, level_y - 7), (bar_right, level_y + 7), radius: 1.5, fill: color, stroke: none)
}
}
arrow((169, ground_y), (169, ground_y - level_gap), color: orange, both: true)
label(
22,
293,
459,
size: 17pt,
centered: true,
)[$P(n) = (1-e^(-x)) e^(-n x)$; bar length = probability.]
label(
22,
326,
461,
size: 15pt,
centered: true,
)[Gap $ℏ omega_"E"$; the ground state still has $E_0 = ℏ omega_"E"/2$. Higher levels omitted.]
callout(20, 368, 464, orange, [Thermal energy competes with the gap])[
$n$ counts excitation quanta of one mode; $P(n)$ is its level probability. $Theta_"E"$ expresses the energy gap as a temperature. Thus $x = Theta_"E" / T$ compares the gap $ℏ omega_"E"$ with thermal energy $k_"B" T$: large $x$ means few excited states.
]
})
// === Heat capacity computed from the oscillator spectrum ===
panel(24, 659, 690, 615, 3, [Why the heat capacity falls on cooling], blue, blue_fill, {
label(
20,
58,
649,
)[Thermal excitations store heat. The fixed zero-point energy contributes no heat capacity.]
equation(
20,
106,
648,
color: blue,
)[$C_V/(3 N k_"B") = (x^2 e^x)/(e^x - 1)^2 quad x = Theta_"E"/T quad Theta_"E" = (ℏ omega_"E")/k_"B"$]
let (plot_left, plot_bottom, plot_width, plot_height) = (70, 352, 576, 170)
let plot_top = plot_bottom - plot_height
label(20, 148, 210, size: 16pt)[Heat capacity / $3 N k_"B"$]
for tick in (0, 0.5, 1) {
let tick_y = plot_bottom - plot_height * tick
segment((plot_left, tick_y), (plot_left + plot_width, tick_y), dash: "dotted")
symbol(plot_left - 19, tick_y, str(tick), size: 16pt)
}
for tick in (0, 0.5, 1, 1.5, 2) {
let tick_x = plot_left + plot_width * tick / 2
segment((tick_x, plot_bottom), (tick_x, plot_bottom + 5))
symbol(tick_x, plot_bottom + 19, str(tick), size: 16pt)
}
segment((plot_left, plot_bottom), (plot_left + plot_width, plot_bottom))
segment((plot_left, plot_bottom), (plot_left, plot_top))
for (heat_capacity, color) in ((debye_cv, teal), (einstein_cv, blue)) {
let points = range(201).map(sample_idx => {
let temperature = sample_idx / 100
(
plot_left + plot_width * temperature / 2,
plot_bottom - plot_height * heat_capacity(temperature),
)
})
line(..points, stroke: 2.8pt + color)
}
segment(
(plot_left, plot_top),
(plot_left + plot_width, plot_top),
color: muted,
thickness: 1.5pt,
dash: "dashed",
)
label(236, 148, 284, size: 16pt)[Classical Dulong–Petit limit: 1]
for (legend_y, color, name) in (
(257, blue, [Einstein: one frequency]),
(300, teal, [Debye: acoustic spectrum]),
) {
// centered on the lowercase letters of the 17pt label, not its baseline
segment((406, legend_y - 6), (442, legend_y - 6), color: color, thickness: 3pt)
label(453, legend_y - 14, 230, size: 17pt, color: color, name)
}
symbol(355, plot_bottom + 40, $T slash Theta$, size: 17pt)
label(
19,
412,
655,
size: 16pt,
centered: true,
)[Cold Einstein: $C_V prop x^2 e^(-x)$ · Hot: $C_V -> 3 N k_"B"$\ Equal $Theta_"E" = Theta_"D" = Theta$ for shape comparison; real fitted scales differ.]
callout(20, 465, 650, blue, [Heat capacity measures energy stored per degree])[
$C_V = ((partial U) / (partial T))_V$ measures how much energy a small temperature rise stores at fixed volume. Classically, each mode contributes $k_"B"/2$ from motion and $k_"B"/2$ from its spring, so $3N$ modes give $3N k_"B"$. At low $T$, a mode stores little extra heat when its excitation gap greatly exceeds $k_"B" T$.
]
})
// === Local oscillators versus collective normal modes ===
panel(732, 659, 424, 615, 4, [Real crystals have phonons], teal, teal_fill, {
label(20, 59, 381)[Atoms move together. A phonon is one quantum of a collective vibration.]
let wave_atoms = range(7).map(site_idx => (
41 + 54 * site_idx,
155 - 15 * calc.sin(site_idx * calc.pi / 3),
))
for (start, end) in wave_atoms.windows(2) { spring(start, end, color: teal, amplitude: 3) }
for position in wave_atoms { atom(..position, color: teal, radius: 7) }
label(20, 188, 381, size: 16pt, centered: true)[Coupled atoms → many normal-mode frequencies]
let (einstein_x, debye_x, axis_y) = (44, 259, 327)
for left in (einstein_x, debye_x) {
arrow((left, axis_y), (left + 136, axis_y), color: guide)
arrow((left, axis_y), (left, axis_y - 80), color: guide)
symbol(left - 7, axis_y - 95, $g(omega)$, size: 16pt)
symbol(left + 139, axis_y + 16, $omega$, size: 16pt)
}
arrow((einstein_x + 61, axis_y), (einstein_x + 61, axis_y - 76), color: blue)
symbol(einstein_x + 61, axis_y + 21, $omega_"E"$, size: 16pt, color: blue)
let spectrum = range(81).map(sample_idx => {
let fraction = sample_idx / 80
(debye_x + 106 * fraction, axis_y - 74 * fraction * fraction)
})
line(..spectrum, stroke: 2.5pt + teal)
segment((debye_x + 106, axis_y - 74), (debye_x + 106, axis_y), color: teal, dash: "dotted")
symbol(debye_x + 106, axis_y + 21, $omega_"D"$, size: 16pt, color: teal)
label(31, 367, 167, size: 16pt, centered: true, color: blue)[One frequency]
label(238, 367, 170, size: 16pt, centered: true, color: teal)[Debye: $g(omega) prop omega^2$]
label(
19,
393,
383,
size: 16pt,
centered: true,
)[Each spectrum contains 3N modes. In 3D, low-frequency acoustic modes give $C_V prop T^3$.]
label(19, 436, 383, size: 14pt, centered: true)[Harmonic normal modes remain independent.]
callout(20, 465, 384, teal, [Why soft modes matter])[
$g(omega) dif omega$ counts modes in a frequency interval. Soft acoustic modes remain easy to excite as the solid cools, giving $C_V prop T^3$ at low $T$. $omega_"D"$ sets the cutoff, with $Theta_"D" = ℏ omega_"D" / k_"B"$.
]
})
// === Exact, enumerable microstates ===
panel(24, 1292, 430, 555, 5, [Count states to get entropy], orange, orange_fill, {
label(20, 62, 389)[One atom: M = 3 modes, q = 2 quanta.\ Six allocations have the same energy.]
for (state_idx, state) in allocations.enumerate() {
let center_x = 80 + 126 * calc.rem(state_idx, 3)
let baseline = 172 + 84 * calc.floor(state_idx / 3)
for (mode_idx, quanta) in state.enumerate() {
let mode_x = center_x + (mode_idx - 1) * 27
rect(
(mode_x - 10, baseline - 43),
(mode_x + 10, baseline),
radius: 3,
fill: rgb("#D8CFC4"),
stroke: none,
)
for quantum_idx in range(quanta) {
atom(mode_x, baseline - 9 - quantum_idx * 16, radius: 6, color: orange)
}
}
symbol(center_x, baseline + 17, [#state.at(0), #state.at(1), #state.at(2)], size: 16pt)
}
equation(19, 298, 390)[$Omega(M, q) = binom(q+M-1, q)$]
equation(19, 347, 390, color: orange)[$S = k_"B" ln Omega quad M = 3N$]
callout(20, 405, 390, orange, [Same energy, different microstates])[
Each bin is an $x$, $y$, or $z$ mode. The total excitation energy is $q ℏ omega_"E"$ above the ground state. $Omega$ counts allocations at fixed $q$: more possibilities mean larger entropy. Here $Omega = 6$ and $S = k_"B" ln 6$.
]
})
// === Classical free-energy application ===
panel(472, 1292, 684, 555, 6, [A reference for solid free energies], purple, purple_fill, {
label(21, 62, 641)[Classical Frenkel–Ladd integration · Helmholtz free energy $F = U - T S$]
let cell_y = 170
for (center_x, coupling, name) in (
(96, 0, [Springs only]),
(335, 0.5, [Blend]),
(583, 1, [Real interactions]),
) {
symbol(center_x, cell_y - 55, $lambda = #coupling$, size: 17pt, color: purple)
reference_cell(center_x, cell_y, coupling)
label(center_x - 84, cell_y + 39, 168, name, size: 17pt, centered: true)
}
for (start_x, end_x) in ((160, 266), (400, 511)) {
arrow((start_x, cell_y - 2), (end_x, cell_y - 2), color: purple)
}
equation(20, 239, 643)[$V_lambda = (1-lambda) V_"E" + lambda V_"real"$]
equation(
19,
283,
645,
size: 25pt,
color: purple,
)[$F_"real" - F_"E" = integral_0^1 chevron.l V_"real" - V_"E" chevron.r_lambda dif lambda$]
label(
21,
332,
641,
size: 15pt,
)[$chevron.l ... chevron.r_lambda$: equilibrium average in the blend. Keep temperature, volume, and the positional constraint fixed along a reversible crystal path. Release the fixed center of mass (or one particle: Einstein molecule) with its analytic free-energy correction.]
callout(20, 405, 644, purple, [Use: compare candidate crystal structures])[
$lambda in [0,1]$ controls the blend. Sampling each value gives the average in the integral, which adds up the reversible free-energy change. The result includes both energy and entropy through $F = U - T S$. At the same temperature, volume, and particle number, the candidate with lower Helmholtz free energy $F$ is favored.
]
})
label(
30,
1868,
1118,
size: 17pt,
color: ink,
)[*Symbols:* $T$ temperature · $k_"B"$ Boltzmann constant · $ℏ$ reduced Planck constant · $C_V$ heat capacity at fixed volume · $g(omega)$ mode density.]
label(
30,
1910,
1118,
size: 16pt,
)[$U$ internal energy · $V$ potential energy · $q$ excitation quanta. Heat curves include lattice vibrations only; no electronic or magnetic contribution. Thermal equilibrium is assumed.]
})
